Citronic CDM10:4mk4 4-Channel DJ Mixer
The New CDM3:2X from Citronic offers unrivalled quality and features at an amazing price. It’s compact, taking up only three rack spaces, but with a clean and simple layout it offers ample space between its functions. The CDM3:2X features a total of eight inputs, including three microphone, and five line inputs each input is via a gold-plated RCA phono sockets. Microphones 1 and 2 have individual gain controls, a shared 3-band EQ and On/Off/talkover switch, the aux channel features the 3rd microphone input and a switchable aux (line) input, individual gain control and a 45mm channel fader. Channels 1 and 2 feature a total of 4 switchable inputs, individual gain control and a 45mm channel fader, these channels are routed through the 45mm rail-glide crossfader, which is a user replaceable component. The fourth fader is the master output channel, this features a stereo/mono selector switch, 45mm fader and also the booth output rotary control. There is a 5-band master EQ, 10-bar LED monitor for checking levels, a 12V BNC light socket as standard, the headphone section features a headphone mix facility allowing the user to hear the master output, cue output or a mix of both. Inside the CDM3:2X features SMT technology, this helps prevent unwanted noise, and channel bleed, making this a superb mixer for any DJ.
|
|
Product features:
3 Channel 19” 3U 8 input DJ mixer
2 Master mic inputs with individual gain controls and shared 3-band EQ
Auxiliary channel with 3rd mic and line inputs
2 Music channels with individual gain control and switchable inputs
45mm Rail-glide replaceable crossfader
5-band master EQ
Booth output
Stereo/mono switch
Headphone mix control
10-Bar LED monitor
12V BNC light socket
Gold Plated RCA inputs and outputs
IEC power lead with power On/Off switch
Specifications:
Dimensions - 483 x 132 x 90mm (3U)
Power supply - 230Vac, 50Hz
Weight - 3kg
THD - < 0.01%
Signal to noise ratio:Mic - 70dB
Frequency response:Mic - 30Hz - 20KHz (±1dB)
Cutout - 450 x 128mm
Frequency response:Line - 20Hz - 20KHz (±1dB)
Equalizer - 63Hz, 250Hz, 1KHz, 4KHz, 8KHz (±12dB)
Signal to noise ratio:Line - 90dB
Crosstalk - < -80dB
|
