Balanced inputs
High-pass filter, low-pass filter can be switched on additionally for each channel
Level adjustment on the rear, protected against tampering
8Ω bridge operation possible
LED VU meter and LED indication for overload (Clip) for each channel
Soft start
Groundlift switch
Speaker switch-on delay
Fan-cooling
Protected against short circuit, overheating, and DC voltage overlay at the outputs
Soundcheck 01/2006
'Presents itself as a powerful unit during monitor operation at stage performances in a club. The multichannel concept of these amplifiers works out perfectly.'
PROSOUND 03/2006
'Can solve a lot of problems all at once. Is worth every cent of its price.'
Technical Data
Stereo 4Ω - 8 x 160WRMS
Stereo 8Ω - 8 x 100WRMS
8Ω bridge operation - 4 x 320WRMS
Max. power - 1,800WMAX
Inputs - 0.7V/20kΩ
Frequency range - 12-60,000Hz/-1.5dB
S/N ratio - > 80dB
Crosstalk attenuation - > 60dB
THD - < 0.1%
Power supply - 230V˜/50Hz/2,400VA
Admiss. ambient temp. - 0-40 °C
Dimensions - 482x132x310mm, 3RS
Weight - 19kg
Connections - 8 x XLR, bal. and 8 x screw terminal
|
