Portable amplifier system,
with integrated adjustable multifrequency receiver unit with UHF PLL
technology.
Ideally suited for mobile applications, e.g. at sales events, lectures
Robust plastic housing of compact size with carrying handle and carrying
strap
Operation via built-in rechargeable lead gel battery 12V/2.7Ah
(operating time: up to 3 hours) or supplied switch-mode PSU
Integrated automatic charging of rechargeable battery
1 wireless microphone channel with 16 selectable UHF frequencies (863-
865MHz) and volume control
1 microphone input via 6.3mm mono jack, 1 line input via 3.5mm mono
jack, common volume control and tone control
1 mix output via 3.5mm mono jack
9mm ( 3/8 ') stand thread, can be mounted onto a speaker stand with
standard diameter with stand adapter EBH-48 (available at option)
Supplied with practical protective shoulder bag which can stay on during
operation
Technical Facts
Amplifiers Output power50WMAX/36WRMS
Frequency range60-15,000Hz
Carrier frequency863-865MHz
Rangeapprox. 30m
Mic inputs 10mV
Line inputs 100mV
Mix output 560mV
Equalizer±8dB/10kHz
Power supplyrech. batt. 12V/2.7Ah,
19V DC current /2.6A via
suppl. PSU 100-240V˜/50-60Hz/180VA
Admiss. ambient temp.0-40 °C Dimensions160x210x290mm
Weight4.2kg
Microphone
Hand-held microphone with integrated multifrequency transmitter,
with UHF PLL technology. Matching the portable amplifier systems TXA-110 and TXA-120.
Dynamic microphone cartridge, cardioid characteristic
16 selectable UHF frequencies (863-865MHz)
Battery status indication
Transmitting power: < 10mW (EIRP)
Power supply via 2 x 1.5V battery AA size (not supplied)
Technical Facts
Microphones Carrier frequency 863-865MHz
Audio frequency range 50-18,000Hz
Frequency stability ±0.005%
DimensionsØ 50mm x 255mm
Weight 290g
Suitable for portable amplifier systems TXA-110 and TXA-120
Please note this systems includes 1 x handheld microphone
|
