 Triple Output Regulated Power Supply With Variable Outputs 2 x 0-30V / 0-3A + 5V / 3A Fixed |
Triple Output Regulated Power Supply With Variable Outputs 2 x 0-30V / 0-3A + 5V / 3A Fixed
Regulated power supply with dual variable output voltages from 0-30Vdc and a fixed 5V/3A output.
The unit consists of two identical, independently adjustable power supplies, and one fixed 5V/3A DC power supply. A front panel switch selects one of three modes of operation: independent, series and parallel. The power supply is regulated giving constant current/voltage supply and a full rated, maximum current output which can be continuously adjusted throughout the output range.
Features
The setting of the output voltages can be coupled (master/slave)
Series and parallel switchable output
Incorporates short circuit and 'FOLDBACK' over load protection
Variable voltage and current limiting
Housed in a solid metal case
Power switch fitted
Outputs via red, black and green 4mm terminal sockets
The output voltage and the supplied current are indicated with 2 green LED displays for voltage and 2 red LED displays for current
Air cooled
DC output standby function
Specification
Power supply 230Vac, 50Hz
Accuracy : 5V output 5V (±0.25V)
Line regulation CV<0.01%+3mV, CC<0.2%+3mA
Line regulation : 5V output <5mV
Line regulation : Series <0.01% (+5mV)
Load regulation CV<0.01%+3mV, CC<0.2%+3mA
Load regulation : 5V output <15mV
Load regulation : Series < 300mV
Output Current : Fixed 3A
Output Current : Variable 2 x 0-3A
Output voltage : Fixed 5V
Output voltage : Variable 2 x 0-30V
Parallel operation Line Regulation <0.01%+3mV, Load Regulation <<0.01%+3mV (rating current 3A)
Ripple & noise <1mV rms, 5Hz - 1MHz
Ripple & noise : 5V output <2mV rms
Ripple current <3mA rms
Dimensions 255 x 150 x 330mm
Weight 8.1kg
|
|
|
|
|
|
