Cloud Electronics ME-1 Microphone Input Wall Panel
The Cloud Electronics ME-1 Microphone Input Wall Panel input connector plate provides two balanced microphone inputs, and is useful in multi-purpose areas where mics are sometimes needed. The ME-1 has adjustable mic level and EQ per input, and connects to one of the DCM-1’s four dedicated Mic Inputs with single screened CAT-5 cable. The ME-1’s two inputs are mixed together at the plate, and the summed mic signal applied to the DCM-1.
Any of the DCM-1’s mic inputs can be routed to any zone without restriction. Inputs on the ME-1 are via latching 3-pin female XLR connectors. 12v phantom power is available on either input if required (set via a jumper accessible from the rear plate).
The ME-1 connects to one of four dedicated ME-1 input ports on a Cloud DCM-1/DCM-1e via a single screened CAT-5 cable. Up to four ME-1 microphone Input plates can be daisy chained together per input port on a Cloud DCM-1/DCM-1e.
