The Adastra Multi Zone 100V Amplifier 5 x 60W is a professional multi-channel slave amplifier designed for distributed audio, paging and multi-room sound installations. Featuring five independent Class D amplifier channels, each with its own dedicated input, this versatile amplifier can operate as a high-power slave unit or as a fully independent zoning amplifier for commercial and professional audio systems.
Supporting both 100V line and low impedance speaker outputs, the amplifier is ideal for retail, hospitality, education, office, leisure and public address applications requiring flexible multi-zone audio control.
Each of the five amplifier channels operates independently, allowing flexible routing and audio distribution across multiple zones.
The RMS-series amplifier supports both 100V line speaker systems and low impedance speaker setups for installation flexibility.
Each amplifier channel features its own independent line input, with the option to switch to a shared global auxiliary source where required.
A dedicated rear-panel paging microphone input provides priority announcements and voice alerts with adjustable VOX override.
Built-in 24V mute contacts allow integration with emergency alarm and evacuation systems for safety-critical installations.
High-efficiency Class D amplification and toroidal transformer design allow the amplifier to fit into a compact 1U rack-mount housing.
| Amplifier Type | Multi-Channel Slave Amplifier |
|---|---|
| Output Channels | 5 |
| Power Output (4 Ohms) | 5 x 60W RMS |
| Power Output (100V Line) | 5 x 60W RMS |
| Speaker Compatibility | 100V or 4-16 Ohm |
| Channel Inputs | 5 x L+R RCA or Balanced Terminal |
| Auxiliary Input | L+R RCA |
| Microphone Input | Balanced XLR (Rear Panel) |
| Mic Controls | Gain, Bass, Treble & VOX |
| Output Controls | Level, Bass, Treble & Ch/Aux Switch |
| Phantom Power | +20V Switchable |
| Emergency Control | 24V Mute Contacts |
| Speaker Output Connection | 5 x 100V / 4 Ohm Euroblock Terminal |
| Power Supply | 170-264Vac, 50/60Hz (IEC) |
| Fuse | T2AL |
| Dimensions | 482 x 330 x 42mm |
| Weight | 8.17kg |
Ideal for schools, offices, retail stores, restaurants, hotels, leisure centres, warehouses, houses of worship, public address systems and commercial multi-room audio installations.
The Adastra RMS multi-zone amplifier provides a flexible professional audio solution for installers needing multiple independent zones, paging functionality, emergency integration and both 100V line and low impedance speaker support within a compact rack-mount design.
