The Biamp REVAMP2150 is a professional 2-channel Class-D power amplifier designed for fixed audio installations requiring high performance, silent operation and exceptional reliability. Delivering up to 2 x 165W dynamic output power at 4Ω, the REVAMP2150 is ideal for commercial audio systems, background music, retail environments, hospitality venues and low impedance speaker installations.
Featuring a slim 1U rack-mount design, convection cooling and extensive amplifier protection circuitry, the REVAMP2150 offers maintenance-free operation and versatile system integration for professional installers.
The REVAMP2150 uses efficient Class-D amplifier technology to deliver powerful and clean audio performance while maintaining low heat generation and energy consumption.
The amplifier can easily be bridged into a more powerful single-channel amplifier for larger speaker loads or high-power applications.
The convection-cooled design operates without internal fans, ensuring silent operation and preventing dust build-up inside the chassis.
Multiple integrated protection systems help safeguard both the amplifier and connected speakers during operation.
The REVAMP2150 is designed for flexible integration into professional audio systems with multiple input and output connection options.
The slim and lightweight chassis makes the REVAMP2150 easy to install in equipment racks and commercial AV systems.
| Specification | Details |
|---|---|
| Amplifier Type | Class-D |
| Channels | 2 |
| Dynamic Output Power (4Ω) | 2 x 165W |
| RMS Output Power (4Ω) | 2 x 150W |
| Dynamic Output Power (8Ω) | 2 x 95W |
| RMS Output Power (8Ω) | 2 x 80W |
| Bridged Output (Dynamic) | 330W @ 8Ω |
| Bridged Output (RMS) | 300W @ 8Ω |
| Minimum Load Impedance | 4Ω per channel / 8Ω bridged |
| Frequency Response | 20Hz – 22kHz |
| Channel Separation | >70dB @ 1kHz |
| Cooling System | Convection Cooled (Fanless) |
| Power Supply | 115 – 230VAC Switching Mode |
| Maximum Power Consumption | 400W |
| Rack Size | 1U 19" |
| Dimensions | 44 x 483 x 239mm |
| Weight | 5.1kg |
Ideal for retail stores, hospitality venues, bars, restaurants, offices, fitness studios, education facilities and commercial low impedance speaker installations requiring silent and reliable amplification.
Q: Does the REVAMP2150 support 100V speaker systems?
A: No, the REVAMP2150 is designed for low impedance speaker systems only.
Q: Is the amplifier fan cooled?
A: No, it uses silent convection cooling with no internal fan.
Q: Can the amplifier be bridged?
A: Yes, it can be bridged into a single 330W dynamic / 300W RMS amplifier at 8Ω.
Q: Is it suitable for commercial AV racks?
A: Yes, the amplifier features a slim 1U 19" rack-mountable chassis.
