Onkyo TX-SR343 5.1 Home Cinema AV Receiver
#IV.TXSR343B
Onkyo TX-SR343 5.1 Home Cinema Receiver
Onkyo TX-SR343 5.1-Channel Home Cinema Receiver
Affordable Home Theater Just Got Better
Surround Sound for Immersive 4K Entertainment
Behind the freshly styled faceplate of the TX-SR343 is high-current Wide Range Amplification Technology to transform your movie, television, and gaming experiences. This receiver has the latest HDMI® connections and supports HDCP 2.2, which means you can stream UltraHD video and spin next-generation 4K Blu-rays. The TX-SR343 is also ready to power and play USB video-subscription streaming devices. The TX-SR343 can up-convert analog video (such as VHS tapes) and send it to your TV through a single HDMI cable for improved picture quality. There’s Bluetooth streaming with audio optimization, and a Burr-Brown DAC to ensure your music is played with pure energy. It’s quite simply our best budget A/V receiver ever.
Features:
- HDMI 4 In / 1 Out (4K UltraHD/HDCP 2.2)
- True Power from Discrete Amplifiers
- Easy Connection Guide on Back Panel
- Bluetooth Audio Streaming
- Streaming Media Player Ready
Advanced Features:
- 4K/60 Hz-Capable HDMI® Terminals for UltraHD Entertainment
- Bluetooth Version 2.1 + EDR Capability (Compatible Profile: A2DP v1.2, AVRCP v1.3)
- Analog Video Upconversion to HDMI
- Advanced Music Optimizer to Improve Compressed Digital Audio Quality (Bluetooth Audio Included)
- Phase-Matching Bass Boost for Deep Bass and Clear Mid-Range
Amplifier Features:
- 100 W/Ch (6 Ω, 1 kHz, 1% THD, 1 Channel Driven, IEC); 120 W/Ch (6 Ω, 1 kHz, 1% THD, 1 Channel Driven, JEITA)
- WRAT (Wide Range Amplifier Technology)
- H.C.P.S. (High Current Power Supply) Massive High Power Transformer
- Discrete Output Stage Circuitry
- PLL (Phase Locked Loop) Jitter-Cleaning Circuit Technology for S/PDIF Audio
Processing Features:
- HDMI Support for 4K/60 Hz, 3D, Audio Return Channel, DeepColor™, x.v.Color™, LipSync, Dolby® TrueHD, DTS-HD Master Audio™, DVD-Audio, Super Audio CD, Multichannel PCM, and CEC
- Dolby® TrueHD and DTS-HD Master Audio™ Decoding
- TI Burr-Brown 192 kHz/24-bit DAC for All Channels
- Advanced 32-bit DSP Chip
- 4 DSP Modes for Gaming: Rock, Sports, Action, and RPG
- Theater-Dimensional Virtual Surround Function
- CinemaFILTER™
- Direct Mode
- Double Bass Function
- Non-Scaling Configuration
- A-Form Listening Mode Memory
Connection Features:
- 4 HDMI Inputs and 1 Output
- USB Port (Rear) for Powering Media Streaming Sticks (5 V, 1 A)
- 2 Component Video Inputs (Rear)
- 3 Composite Video Inputs (1 Front/2 Rear)
- 3 Digital Audio Inputs (2 Optical and 1 Coaxial)
- 7 Analog Audio Inputs (1 Front/6 Rear)
- Subwoofer Pre-Out
- Headphone Jack
