QP2320 Quad Power Amp 4 x 580W

A range of quad power amplifiers with 4 fully independent channels and individual volume controls. Fully balanced line inputs and parallel outputs allow signal daisy-chaining to further amplifiers. Designed as a cost effective and efficient solution for multi speaker installations where sound quality is paramount.

Features:

• Fully balanced signal path
• Stable down to 2 Ohms
• 2U rack-mountable

Specification:

• Power supply - 230Vac, 50Hz (IEC)
• Input : line - 4 x XLRF balanced
• Output : line - 4 x XLRM (parallel from inputs)
• Input impedance - 20k Ohms
• Frequency response - 5Hz - 50kHz
• THD - 0.05%
• Slew rate - 40V/usec
• S/N ratio - 103dB
• Controls - 4 x channel gain
• Speaker : outputs - 4 x SPK connectors
• Circuit protection - Short-circuit, DC, overload, soft-start
• Dimensions - 483 x 439 x 88mm
• Fuse rating - F12A
• Power rms @ 8 Ohms - 4 x 300W
• Power rms @ 4 Ohms - 4 x 450W
• Power rms @ 2 Ohms - 4 x 580W
• Weight - 23.5kg
