DMR-184 H.264 4 Channel CCTV Digital Multiplex Recorder

Compared with previous standards, the data rate will be reduced by half at the same quality. As opposed to customary MPEG-4 standard, it is thus possible to double the recording time with the same hard disk size.

The DMR-184 H.264 4 Channel CCTV Digital Multiplex Recorder use a highly efficient processor technology for the H.264 compression method. This results in a considerably improved display of fast image movements and a faster upload process with Internet connections.

Features:

• Video compression: H.264
• Network connection, access via Internet Explorer
• 2 x USB 2.0 interface for exporting data onto a USB stick and for connecting USB mouse
• VGA output
• Video motion detector, 12x12 sensor surfaces
• Recording speed: up to 100 pictures/sec., depending on the resolution
• 3 recording qualities
• Recording time depends on recording speed, recording quality and hard disk capacity
• Manual recording, alarm-controlled, time-controlled or motion-triggered recording
• Quick search by time list, event list or alarm list
• Password protection
• Brightness, colour, contrast and sharpness can be adjusted for each channel
• Supplied with infrared remote control, USB mouse and software package
• 4 alarm inputs, 1 alarm output
• 4 audio inputs, 2 audio outputs

Supplied without hard disk.

Matching SATA hard disk is available at option.
