The LEDJ Slimline 12Q5 RGBW Batten is a versatile and powerful lighting solution, designed to deliver bright, even colour washes. Featuring 12 x 5W quad-colour LEDs (RGBW), it offers consistent performance across a wide range of applications, from stage and theatre lighting to DJ sets and venue uplighting. Its slim profile and convection cooling make it both discreet and silent during use.
Engineered for professional use, the Slimline 12Q5 boasts a compact yet robust housing that ensures reliability during demanding performances. Its convection-cooled design eliminates fan noise, making it ideal for theatres, studios, and noise-sensitive environments. The supplied bracket enables flexible rigging or floor-standing setups, which offers maximum adaptability.
| Specification | Details |
|---|---|
| Light Source | 12 x 5W RGBW Quad-Colour LEDs |
| Beam Angle | 25 degrees (Field: 40 degrees) |
| Refresh Rate | 400 Hz |
| DMX Channels | 2, 3, 4, or 7 selectable |
| Control Modes | DMX, Sound Active, Auto Run, Primary/Secondary, Manual |
| Effects | 0-100% Dimming, Variable Strobe |
| Power Consumption | 70 W |
| Power Supply | 100-240 V, 50/60 Hz |
| Fuse | F1A 250 V |
| Connections | IEC Power In/Out, 3-pin XLR DMX In/Out |
| Dimensions | 87 x 1018 x 63 mm |
| Weight | 2.2 kg |
The LEDJ Slimline 12Q5 RGBW Batten offers powerful and consistent colour output, well-suited for stage backdrops, architectural washes, or ambient lighting effects. Its silent convection cooling ensures noise-free operation, while the multiple control options provide flexibility for both professional DMX users and beginners. Lightweight and compact, it is an ideal fixture for touring setups and permanent installations alike.
Q: What colours can the Slimline 12Q5 produce?
A: The quad-colour LEDs (RGBW) allow for smooth mixing of red, green, blue, and white for a wide colour spectrum.
Q: Does it operate silently?
A: Yes, the convection cooling design eliminates fan noise, making it ideal for theatres and studios.
Q: Can I link it with other Slimline fixtures?
A: Yes, it can be linked with Slimline 5Q5 and 7Q5 models for consistent lighting setups.
Q: Is a remote control available?
A: It is compatible with the optional LEDJ90C IR remote for simple wireless control.
Q: What is the beam angle?
A: It features a 25 degrees beam angle with a 40 degrees field angle, suitable for both focused and wide washes.
