RBT-95 Ribbon Tweeter 8ohm 60W Max 30W RMS

RBT-95 Ribbon tweeter, 8Ω, 60WMAX, 30WRMS

These magnetostatic speakers of an exceptionally high efficiency achieve a perfectly fine dynamic reproduction of the high range and the brilliance frequency range. The power capability of the system can considerably be increased by voltage dividers (level attenuations which take tweeters to the level of normal HiFi systems) or maybe higher crossover frequencies. These tweeters achieve a very light sound of low distortion which particularly improves the stereophony in applications from 5kHz on. By adding a super tweeter above 8-10kHz, e.g. even high-quality full range systems can be further improved.

RBT-95: round
RBT-95SQ: square

HiFi-Selbstbau, Online magazine 2008

"The most competitive magnetostatic speaker available on the German market. At applications from 5kHz on, it impresses with a high efficiency of 93dB and a low THD at a steep crossover of 12dB/oct. min."

Klang+Ton 06/2006

"A very attractive price and amazingly good measured values ... simply showed a perfect performance."

Technical Specification

• Impedance (Z) 8ohm
• Resonant frequency (fs) 4,500Hz
• Max. frequency range fx-22,000Hz
• Rec. crossover freq. (12dB) 5,000Hz
• Music power > 60WMAX
• Power rating >30WRMS
• SPL (1W/1m) 98dB
• Voice coil diameter -
• Magnet diameter magnetostatic speaker
• Mounting cutout 80x45mm
• Mounting depth 17mm
• Dimensions Ø 95mm
• Weight 120g
