PA-1200 4 Zone Mono PA Mixing Amplifier 120W RMS

#17.0710

This item is available. Please contact us for pricing and ordering. 01371 879 000 or [email protected]

PA-1200 4 Zone Mono PA Mixing Amplifier 120W RMS

The PA-1200 4 Zone Mono PA Mixing Amplifier features bass, treble and master controls, level display via LEDs, a chime which can be activated via external momentary push-button and insertions for various functions that are available at option.

Features:

  • 1 x 120WRMS
  • Chime, continuous sound and wailing sound, automatic mute, chime can also be activated via external momentary push-button, 2-tone chime or 4- tone chime (selectable)
  • Bass, treble and master controls, level display via LEDs
  • 15V phantom power for channels 2 and 3
  • Insertions for various functions are available at option
  • 482mm (19') rack installation with mounting frame PA-1200RM
  • Mains operation and 24V emergency power operation

Technical specification:

  • Output power:
  • 120WRMS
  • 170WMAX
  • Inputs:
  • Mic 1.5mV/600Ω
  • Line 150mV/47kΩ
  • Phono 1mV/47kΩ (RIAA)
  • Outputs:
  • Speakers
  • 1 x 4Ω, 1 x 8Ω,
  • 4 x 70/100V
  • Preamplifier 1V/1kΩ
  • Frequency range 80-15,000Hz
  • Tone control
  • Bass ±10dB/100Hz
  • Treble ±10dB/10kHz
  • S/N ratio
  • Mic > 60dB
  • Line > 70dB
  • THD < 1%
  • Admiss. ambient temp. 0-40 °C
  • Power supply:
  • 230V˜/50Hz/280VA,
  • 24V DC current /11A
  • Dimensions 420x122x350mm
  • Weight 13kg
  • Inputs:
  • Mic 1 x 6.3mm jack
  • Mic/line 3 x XLR, bal.
  • Line 1 x RCA L + R
  • Phono/line 1 x RCA L + R
  • Telephone 1 x twin spring-load. term.
  • Outputs:
  • Tuner 1 x twin spring-load. term.
  • Chime mom. push-button1 x twin spring-load. term.
  • 1 x preamplifier1 x 6.3mm jack
  • Speakers 7 x screw terminal
  • Power supply 230V˜
  • 1 x 3-pin IEC jack
  • 24V DC current 2 x binding post
