The Australian Monitor TXG30 is a professional-grade wall-mount loudspeaker designed for commercial audio installations in environments such as retail spaces, hospitality venues, educational institutions, and corporate facilities. It offers versatile mounting options and is suitable for both 100 V line and low-impedance systems, making it ideal for background music and public address applications.
The TXG30 features a durable enclosure with a 4" woofer and a 1" dome tweeter, delivering clear and well-balanced sound. Its compact design allows for unobtrusive installation, and the included U-bracket facilitates flexible mounting orientations. The speaker is available in both black and white finishes to complement various interior designs.
| Specification | Details |
|---|---|
| Power Source | Passive (requires external amplifier) |
| Impedance | 8Ω (bypass) |
| Power Taps (100 V) | 30W, 15W, 7.5W, 2.5W |
| Frequency Response (±3 dB) | 100 Hz - 20 kHz |
| Frequency Range (±10 dB) | 80 Hz - 22 kHz |
| Sensitivity (1W/1m) | 104 dB |
| Maximum SPL | 107 dB (program), 110 dB (peak) |
| Dispersion (H x V) | 50 degrees x 60 degrees (-6 dB points) |
| Drivers | 4" woofer, 1" dome tweeter |
| Mounting | U-bracket (included) |
| Colour Options | Black or White |
Its focused dispersion ensures targeted sound coverage, reducing unwanted reflections and enhancing speech intelligibility. The speaker's design allows for easy integration into existing systems, and its durable construction ensures long-term reliability in demanding environments.
Q: Can the TXG30 be used in both 100 V line and low-impedance systems?
A: Yes, the TXG30 supports both 100 V line operation with multiple power taps and 8Ω low-impedance configurations, offering flexibility for various installation requirements.
Q: Is the mounting bracket included with the speaker?
A: Yes, a U-bracket is included in the package for easy and flexible installation.
Q: What type of amplifier should be used with the TXG30?
A: You should use a compatible commercial-grade amplifier capable of delivering appropriate wattage for either 100 V or 8Ω operation.
Q: Is the TXG30 suitable for outdoor use?
A: The TXG30 is primarily intended for indoor use. For outdoor installations, ensure adequate weather protection or consider a weatherproof alternative.
Q: What environments is the TXG30 ideal for?
A: The TXG30 is ideal for commercial spaces such as cafes, retail stores, office buildings, schools, and conference rooms where reliable, high-quality audio is essential.
