The LEDJ Intense 9P10 RGBWA LED Slim Par is a high-performance lighting fixture designed for both professional and enthusiast applications. Featuring nine 10W five-colour LEDs (Red, Green, Blue, White, Amber), it offers advanced colour mixing capabilities, including both pastel shades and rich warm tones. This robust, slimline par is ideal for diverse applications, from uplighting medium venues to lighting stages for live performances. The convection-cooled chassis ensures silent operation, making it perfect for environments where noise is a concern.
Constructed with a durable aluminium housing, the Intense 9P10 is built to endure the demands of touring and permanent setups. Its slim profile allows for discreet placement, while the bracket design supports multiple rigging or floor-standing applications. The fixture includes a quick-release omega clamp for easy mounting and features mounting points for an optional barn door/gel frame kit (LEDJ253A). The convection cooling system eliminates the need for fans, ensuring silent operation and reducing maintenance requirements.
| Specification | Details |
|---|---|
| Power Source | Corded |
| LED Configuration | 9 x 10W RGBWA LEDs |
| Beam Angle | 25 degrees (Field Angle: 35 degrees) |
| Lux @ 2m (Full On) | 4,950 Lux |
| Refresh Rate | 3kHz |
| DMX Channels | 5 / 7 / 9 selectable |
| Control Modes | Static Colour, Colour Change, Colour Fade, Auto, Sound Active, Master/Slave, DMX |
| Dimming | 0-100% |
| Strobe | Variable |
| Power Input/Output | PowerTwist TR1 |
| DMX Input/Output | 5-Pin XLR |
| Cooling | Convection |
| Power Consumption | 110W |
| Power Supply | 100-240V, 50/60Hz |
| Fuse | T2A 250V |
| Dimensions (H x W x D) | 295 x 260 x 93 mm |
| Weight | 2.6 kg |
The LEDJ Intense 9P10 delivers exceptional performance with its high-output LEDs and advanced colour mixing capabilities. Users appreciate its silent operation, thanks to the convection cooling system, and its versatility in various lighting setups. The fixture's multiple control options, including DMX and sound activation, provide flexibility for different event requirements. Its robust build and compact design make it a reliable choice for both touring professionals and fixed installations.
Q: Can the Intense 9P10 be used for both floor-standing and rigged applications?
A: Yes, the fixture's bracket allows for multiple rigging or floor-standing applications, providing versatility in setup.
Q: Is the unit suitable for silent environments?
A: Absolutely. The convection-cooled design ensures silent operation, making it ideal for settings where noise levels must be minimal.
Q: What are the DMX channel options available?
A: The Intense 9P10 offers 5, 7, or 9 selectable DMX channels, allowing for flexible control configurations.
Q: Does the fixture support power linking?
A: Yes, it features PowerTwist TR1 input/output for daisy-chaining multiple units, streamlining power distribution.
Q: Are there optional accessories available?
A: An optional barn door/gel frame kit (LEDJ253A) is available for enhanced beam control and colour filtering.
