The Equinox Merlin 80W is a compact and powerful multi-gobo lighting effect designed for mobile DJs, nightclubs, weddings, and live events. Equipped with an 80W cool white LED and a mirrored barrel, it projects vibrant, moving gobos across walls and dance floors. The fixture offers intuitive operation with manual focus adjustment and an OLED display, supporting DMX, auto, sound-active, and primary–secondary modes.
Constructed with a robust housing, the Merlin 80W ensures durability and reliability for various event settings. Its compact dimensions (314 x 283 x 162mm) and lightweight design (2.5kg) facilitate easy transport and installation. The fixture includes a hanging bracket for versatile mounting options.
| Specification | Details |
|---|---|
| Power Source | Corded |
| LED Type | 80W Cool White LED (7500K) |
| Beam Angle | 4° per beam |
| Gobos/Colours | 8 static gobos/colours + open |
| DMX Channels | 2 / 6 / 9 selectable |
| Pan / Tilt | 180° / 360° |
| Dimming | 0–100% |
| Strobe | Variable |
| Power Consumption | 80W |
| Power Supply | 100–240V, 50/60Hz |
| Fuse | F3A 250V |
| Dimensions (H x W x D) | 314 x 283 x 162mm |
| Weight | 2.5kg |
The Equinox Merlin 80W delivers high-impact lighting effects in a compact form factor. Its powerful LED and mirrored barrel produce sharp, dynamic projections, while the versatile control options cater to both novice and experienced users.
Q: Is the Equinox Merlin 80W suitable for small venues?
A: Yes, its compact size and powerful output make it well-suited for small to medium venues.
Q: Can I control multiple units simultaneously?
A: Yes, the fixture supports primary–secondary mode for synchronised operation of multiple units.
Q: Does it require a DMX controller?
A: While DMX control offers advanced programming, the fixture also operates in auto and sound-active modes without a controller.
Q: How do I adjust the focus?
A: Manual focus adjustment is located at the rear of the fixture for easy beam sharpness control.
Q: What is included with the fixture?
A: The Equinox Merlin 80W comes with a hanging bracket for mounting.
