The Audac SCP206 is a compact and efficient dual-channel Class-D power amplifier, delivering 2 x 60W at 4 Ohms or 1 x 120W in 70/100V bridge mode. Designed for commercial audio installations, it is ideal for applications such as background music systems, public address setups, and distributed audio in venues like retail spaces, hospitality environments, and corporate facilities.
Housed in a sturdy steel chassis, the SCP206 features a half 19-inch rack width and 1U height, allowing for flexible installation options including desktop placement or rack mounting using optional adapters. Its convection-cooled design ensures silent operation, making it suitable for noise-sensitive environments.
| Specification | Details |
|---|---|
| Power Source | 100-240 V AC, 50/60 Hz |
| Amplifier Technology | Class-D |
| Continuous Power Output (AES) | 2 x 60W @ 4Ω, 2 x 30W @ 8Ω, 120W @ 70/100V (Bridge) |
| Frequency Response (±3 dB) | 20 Hz - 20 kHz |
| Total Harmonic Distortion + Noise (1 kHz) | < 0.05% |
| Signal-to-Noise Ratio | > 95 dB |
| Inputs | 3-pin Euro Terminal Block (Pitch - 3.81 mm) |
| Outputs | 4-pin Euro Terminal Block (Pitch - 5.08 mm) |
| Control Interfaces | RJ45 for WP2xx series remote panels, Gain control potentiometers (rear), Stereo Low Z & Mono High Z switch, 70/100V switch, Priority mute contact |
| Cooling | Convection cooled |
| Construction Material | Steel |
| Dimensions (W x H x D) | 217.5 x 44 x 300 mm |
| Weight | 2.70 kg |
| Mounting Options | 1/2 19" / 1 HE or tabletop |
| Additional Features | Energy-saving standby mode, VU LED bar (front), Optional 19" Rackmount adapter, Compatible with WP2xx Universal wall panels |
The SCP206 delivers clear and reliable audio amplification, maintaining a frequency response of 20 Hz to 20 kHz with a total harmonic distortion of less than 0.05%. Its high signal-to-noise ratio (>95 dB) ensures minimal background noise, providing a clean audio output. The amplifier's design facilitates easy integration into existing systems, and its energy-efficient operation contributes to lower operational costs.
Q: Can the SCP206 be used in both low and high impedance systems?
A: Yes, the SCP206 supports both 4/8 Ohm low impedance and 70/100V high impedance configurations, making it versatile for various installation scenarios.
Q: Is the amplifier compatible with remote control panels?
A: Absolutely. The SCP206 features an RJ45 connector for seamless integration with WP2xx series remote wall input panels and volume controllers.
Q: Does the amplifier have any energy-saving features?
A: Yes, it includes an energy-saving standby mode that activates after a period of inactivity, aligning with Energy Star standards.
Q: What cooling mechanism does the SCP206 employ?
A: The SCP206 utilises passive convection cooling, ensuring silent operation without the need for fans.
Q: What are the installation options for the SCP206?
A: The amplifier's compact design allows for desktop placement or rack mounting using optional adapters, fitting into half 19-inch rack spaces.
