The Audac WP210 is a versatile remote wall mixer designed for easy integration with various AUDAC hardware, including the ARES5A, MTX series, and AMP523. This unit is ideal for professional audio installations in environments such as educational institutions, corporate offices, retail spaces, and hospitality venues. It facilitates the transmission of high-quality audio signals over long distances using cost-effective CAT5e or better cabling, ensuring minimal interference and noise.
Constructed with an elegant ABS front panel complemented by a glass finish, the WP210 boasts a sleek design that blends effortlessly into any setting. Its compact dimensions (80 x 80 mm) make it compatible with standard EU-style in-wall boxes, suitable for both solid and hollow walls. The unit is available in two colour variants: White (RAL9003) and Black (RAL9005), allowing for aesthetic flexibility in various installation environments.
| Specification | Details |
|---|---|
| Inputs | 3.5 mm stereo line input (front), XLR microphone input (front), 6-pin terminal block for rear inputs |
| Outputs | 8-pin terminal block for audio signal transmission |
| Control Features | Individual level controls for mic and line inputs, DIP switches for phantom power, low-cut filter, mono/stereo selection |
| Dimensions (W x H) | 80 x 80 mm |
| Front Finish | Elegant ABS with glass |
| Colours Available | White (RAL9003), Black (RAL9005) |
| Mounting Compatibility | Compatible with standard EU (80 x 80 mm) in-wall boxes; suitable for both solid and hollow walls |
| Certifications | CE, RoHS, FCC Part 15C, cTUVus, REACH compliant |
The WP210 delivers exceptional audio performance, allowing users to mix microphone and line-level inputs seamlessly. Its user-friendly interface, combined with the flexibility of front and rear connections, makes it an ideal choice for both temporary and permanent installations. The unit's compatibility with standard cabling and mounting systems ensures a straightforward installation process, while its robust construction guarantees long-term reliability.
Q: Can the WP210 provide phantom power for condenser microphones?
A: Yes, the WP210 includes a DIP switch on the rear panel to enable or disable phantom power, accommodating condenser microphones that require it.
Q: Is it possible to connect both a microphone and a line-level device simultaneously?
A: Absolutely. The WP210 is designed to handle both inputs concurrently, with individual level controls allowing for precise mixing of the two signals.
Q: What type of cabling is recommended for connecting the WP210 to other AUDAC devices?
A: The WP210 utilises twisted pair cabling, specifically CAT5e or better, for optimal audio signal transmission with minimal interference.
Q: Can the WP210 be mounted on the surface if in-wall installation isn't feasible?
A: Yes, AUDAC offers the WB200 surface mount wall box, which is compatible with the WP210, providing flexibility in installation options.
Q: Is the WP210 suitable for use in environments with high electromagnetic interference?
A: The WP210 is designed with signal transmission that is resistant to interference and noise, making it suitable for environments with potential electromagnetic disturbances.
